Output power: 400W Max
Leakage Current: <1mA(Vin:230)
Working Temperature: -30℃~70℃
Heat dissipation method: Natural cooling
Storing temperature: -40~80℃
Input voltage: 100-240Vac,47-63Hz
Protection: Input under-voltage protection, Output short circuit protection, Input under-voltage recovery point,Output current limiting protection point
Efficiency factor: 0.95@230Vac
Dimention L*W*H (mm): 220×52×26.5±0.5
| Model NO. |
Category |
Output Volt. | Output current | Ripples | Efficiency |
|---|---|---|---|---|---|
| JPS400PV5.0 | Constant Voltage | 5.0V DC | 80A | ≤250mV | ≥90% |
